OLED (Organic Light-Emitting Diode) is a self light-emitting technology composed of a thin, multi-layered organic film placed between an anode and cathode. In contrast to LCD technology, OLED does not require a backlight. OLED possesses high application potential for virtually all types of displays and is regarded as the ultimate technology for the next generation of flat-panel displays.

This is a 1.3 inch blue OLED display module.  It is having a resolution of 128×64. The package includes a display board, a display, 6 pin male header pre-soldered to board. The display module can be interfaced with any microcontroller using SPI/IIC protocols.

Features:

• Only Need 2 I/O Port to Control

• Resolution: 128 x 64 pixels

• Factory configured for SPI protocol (can be easily changed to IIC)

• Working temperature: -30°C ~ 70°C

• Fully Compatible with Arduino

• Driving Voltage: 3.3-5V

Pin Details:

• GND (power ground)

• VCC (positive power supply)

• SCL (clock line)

• SDA (data line)
